4K DVI KVM USB2.0 Extender Set with Audio and EDID via Single LC Fiber for 10km

4K DVI KVM USB2.0 Extender Set with Audio and EDID via Single LC Fiber for 10km

495000 CFA

Product Highlights

Delivers UHD Picture Quality at Resolutions up to 3840x 2160 (4Kx 2K) @30Hz
Supports Ultra Long Distance Transmission up to 10KM
Supports LPCM 7.1, Dolby® TrueHD, and DTS-HD Master Audio
Plug-and-play Operation with No Software Required for Easy, Immediate Installation
Supports Keyboard & Mouse Signal Transmission

3840x 2160@30Hz DVI KVM Extender via Fiber to 10km

4K@30Hz DVI Extender is a compact and high-performance solution which provides remote KVM (USB keyboard, USB mouse and 4K x 2K UHD DVI monitor), DVI and audio signals access to a USB computer up to 10KM away via a simplex LC fiber optic cable. Each KVM extender consists of a local unit that connects to a computer, and a remote unit that connects to a keyboard, monitor and mouse.The Transmitter and Receiver are plug-and-play, and work without any set-up. Compact enclosures are easy to install and can be hidden away.

Specifications
Max Resolution
3840x 2160@30Hz
Total Data Rate
10Gbps
Signal Type
DVI
Wavelength
1310nm/1550nm
Video Input Connector
(1) DVI Type A 19-pin Female
Connectors
BIDI LC
Operating Distance
10km@SM fiber
Dimensions (HxWxD)
5.1"x3.1" x1.1"(130x79x28mm)
Working Temperature
-40°C~60°C
Relative Humidity
0%~95% (Non-condensing)
