NS6240-V3, 2U Twin Server, Dual Socket Intel® Xeon® Scalable Processors Per Node, 2 x 32GB DRAM, 1 x 2.5" PCIe 5.0 SATA SSD Drive Bays, 1 x RJ45 1GbE Ports, 2200W Redundant

NS6240-V3, 2U Twin Server, Dual Socket Intel® Xeon® Scalable Processors Per Node, 2 x 32GB DRAM, 1 x 2.5" PCIe 5.0 SATA SSD Drive Bays, 1 x RJ45 1GbE Ports, 2200W Redundant

15500000 CFA

 3-Year Warranty


Product Highlights

Dual Socket Support 5th/4th Gen Intel® Xeon® Scalable Processors Per Node
16 DIMM Slots Supporting up to 4TB of Memory Per Node
2 PCIe 5.0x 8 and 1 PCIe 5.0x 16 LP Slots
Network Connectivity via AIOM Per Node
2 PCIe 5.0 NVMe/SATA and 10 PCIe 4.0 NVMe/SATA Drive Bays Per Node
Suitable for High-Performance File System, Diskless HPC Clusters, Scale Out All-Flash NVMe Storage and Big Data Analytics

2U Twin Server, Dual Socket Intel® Xeon® Scalable Processors Per Node, 2 x 32GB DRAM, 1 x 2.5" PCIe 5.0 SATA SSD Drive Bays, 1 x RJ45 1GbE Ports, 2200W Redundant

The NS6240-V3 is a high-performance computing server with Intel® C741 chipset. It supports dual socket 4th/5th gen Intel® Xeon series processors. It supports up to 8 TB memory and 12x 2.5" PCIe 5.0 NVMe/SATA Drive Bay, with optional support for 2x M.2 PCIe 4.0 x4 NVMe slot(s). Integrated BMC chip enables easy management, I/OA tech, link convergence, and binding redundancy. Optional KVM OVER IP for out-of-band management.

The new-generation NS6240-V3 accelerated computing server is mainly used in high-performance file system, diskless HPC clusters, scale-out all-flash NVMe storage, and Big Data Analytics.

Specifications
Form Factor
2U Rackmount
Processor
Standard Configuration-2x Intel® Xeon® Silver 6430 Processor-32C 2.1G 270W(Per Node)
Chipset
Intel® C741
Drive Bays
Standard Configuration-1x 480G 2.5" SATA SSD Total 8 Bays
Memory
Standard Configuration-2x 32G DDR4 RDIMM (Per Node)
Expansion Slots
Standard Configuration-2x PCIe 5.0x 8 1 PCIe 5.0x 16 (Per Node)
Raid Controller
Support RAID 0,1,5,10
Fans
4x 16.5K RPM Heavy Duty 8cm Fans
Ethernet
Standard Configuration-2x 10GBase-T (AIOM) Ports
Power Supply
2x 2200W Redundant Titanium Level (96%) Power Supplies
System BIOS
AMI 32MB Flash ROM
Operating Temperature
10°C ~ 35°C (50°F ~ 95°F)
Chassis (HxWxD)
449x88x730mm (17.68"x3.47"x28.75")
Gross Weight
80.7 lbs (36.6 kg)
Management Software
BMC Web GUI/Redfish APIs/IPMI 2.0/SNMP3.0
Operating System Management
WS 2022/RHEL 9.0/ESXi 8.0
