Customized NS6240, 2U High-Density Server, UP to 16 x 4TB of Memory, 12 x 3.5''/2.5'' Hot-swap SAS/SATA/NVMe Drive Bays, 8 x RJ45 1GbE Ports, 2200W Redundant

Customized NS6240, 2U High-Density Server, UP to 16 x 4TB of Memory, 12 x 3.5''/2.5'' Hot-swap SAS/SATA/NVMe Drive Bays, 8 x RJ45 1GbE Ports, 2200W Redundant

15200000 CFA

 3-Year Warranty


Product Highlights

16 DIMMs - up to 4TB ECC 3DS LRDIMM or RDIMM DDR4 2933MHz Per Node
3x 3.5''/2.5" SATA3 Hot-swappable Drive Bays Per Node
2 PCIe 3.0x16 Half-height Expansion Slots Per Node
Support RAID 0, 1, 5, 6, 10, 50, 60
Support a Wide Range of Operating Systems
Suitable for High-end Enterprise, Data Center, HPC and Cloud Computing Environments

Specifications

NS6240, 2U High-Density Server, UP to 16 x 4TB of Memory, 12 x 3.5''/2.5'' Hot-swap SAS/SATA/NVMe Drive Bays, 8 x RJ45 1GbE Ports, 2200W Redundant

The FS 2U quad-node server architecture is market-proven and offers exceptional throughput, storage, networking, I/O, memory and processing power in a 2U form factor.FS offers a range of pre-configured options for versatility to meet the needs of modern and evolving businesses. When configuring your custom server, you'll have the choice of 8 second-generation Intel® Xeon® Scalable series processors, 8~64 16/32G memory, 4~12 SAS/SATA/NVMe hard drives and up to 8 PCIe Gen 3.0 expansion slots.
The server focuses on providing data centers with a scale-outX86server solution, while bringing new economics to data centers in terms of server density, power consumption, andthermaloptimization and total cost of ownership.

Specifications
Form Factor
2U 4 Nodes
Number of Processors
8
Chipset
Intel C621 Series Chipset
Memory
16 DIMM Slots - Support ECC 3DS LRDIMM or RDIMM DDR4 2933MHz, Up to 4TB (Per Node)
Drive Bays
3x 3.5''/2.5'' SATA3 Hot-swappable Drive Bays (Per Node)
Expansion Slots
8 PCIe 3.0x 16
Raid Controller
Support RAID 0, 1, 5, 6, 10, 50, 60
Fans
4 Non-hot-swappable Fans
Ethernet
8x 1GBase-T Ports
Power Supply
2x 2200W Titanium Redundant Power Supply
Management Software
BIOS | BMC | IPMI2.0 | iKVM
Operating System Management
Windows Server 2019 | VMware ESXi 7.0 | RedHat Linux 8.5
Dimensions (HxWxD)
3.4''x17.2''x30.4'' (88x438x774mm)
Weight
59.3lbs (26.88KG)

Product Spotlights

Dense Optimized

Up to 4 half-width dual-way server nodes and 12x 3.5" hot-swappable hard drives in a single 2U frame

Supports 3x 3.5" hot-swappable hard drives per node

Standard support for SATA HDD, optional support for SAS 3008 and 3108 versions, support for built-in DOM

Each node supports a network expansion module (SIOM) for user flexible networking options such as 1G, 10G, 25G, 40G or 100G

Each node supports 2 half-height PCIe 3.0x16 expansion slots at the same time


Intelligent Management Automation

Integrated BMC management to grasp the system operation status in real time, support pre-alarm, failure recovery function

Support IPMI2.0

Provide 1 RJ45 management network port per node

Support remote management

Support iKVM


Workload Optimized Support

Dual Socket 2nd Gen Intel®xeon® Silver 4210 Processors Per Node

With central cooling fan and 2 shared titanium (96%) hot-swappable power supplies

Swappable server nodes , power supplies and disk drives

Quality Certifications
