7.36kW Single-Phase 32A/230V Monitored PDU, (36) C13 & (6) C19 Outlets, IEC 309 32A 2P+E Plug, 10ft Cord, 0U Vertical

7.36kW Single-Phase 32A/230V Monitored PDU, (36) C13 & (6) C19 Outlets, IEC 309 32A 2P+E Plug, 10ft Cord, 0U Vertical

493000 CFA

Product Highlights

User-defined Alarm Thresholds Avoid Circuit Overload Through Real-time Monitoring
Switch-Free Design Against Accidental Power Shut Down
Operation Logs to Record and View Historical Data for Quick Fault Location
Daisy Chain up to Three Rack PDUs and One Host over a Single IP Address
Supporting Web, Telnet, SSL, SNMP v1/v2c, NTP, SMTP and Zabbix Software for Local and Remote Management
Update Hot-swappable Ammeters Without Interfering with IT Equipment Operation

7.36kW Single-Phase 32A/230V Monitored PDU, 36 C13 & 6 C19 Outlets, IEC 309 32A 2P+E Plug, 10ft Cord, 0U Vertical

Power status can be monitored over the RS485 communication interface, or locally by using the LCD hot swapping display to warn of potential overloads. It supports user-specified alarm notification thresholds and enables the data center managers can evaluate energy usage trends and ensure maximum uptime.Remote and local monitoring enables off-site and on-site tracking of PDU vital signs and provides egress control for individual and network customers.Digital display that provides visualization of current strength, voltage, power, IP address and other PDU information.

Specifications
PDU Type
Monitored
Phase
Single-phase
Input Plug Type
IEC 309 32A 2P+E
Output Socket Type
36 C13 & 6 C19
Input Voltage
230V
Output Voltage
230V
Input Current Limits
32A
Rating Current
32A
Load Capacity
7.36kW
Frequency Compatibility
50/60Hz
Cord Length
10ft (3m)
Cord Gauge
10AWG
Ammeter
LCD Hot Swapping
Circuit Breaker
2, Magnetic-hydraulic
Front Panel LCD Display
Digital meter reports PDU output current in amps, voltage, capacity, electric energy, temperature and humidity, and IP address information
Network Compatibility
10/100Base-T
SNMP Compatibility
Supporting Web, Telnet, SSL, SNMP v1/v2c, NTP, SMTP and Zabbix software for local and remote management
Material of Construction
Aluminium Alloy
No. of Rack Spaces
Vertical (0U)
Dimensions (HxWxD)
74.0"x2.20"x1.75" (1879x56x44.5mm)
Toolless Mounting Peg
Unmovable
Rack Mount Brackets
Unmovable
Operating Temperature
0°C~55°C (32°F ~ 131°F)
Relative Humidity
10~95%, Non-condensing
Quality Certifications
