4K HDMI Extender Set with Audio, EDID and RS232 via Single LC Fiber for 10km

510000 CFA

 1-Year Warranty

Product Highlights

Delivers UHD Picture Quality at Resolutions up to 3840 x 2160 (4K x 2K) @ 30 Hz

Supports Ultra Long Distance Transmission up to 10 KM

Supports LPCM 7.1, Dolby® TrueHD, and DTS-HD Master Audio

Local HDMI Port Allows Displays with Different Resolutions without Affecting 4K Signal

Plug-and-play Operation with No Software Required for Easy, Immediate Installation

3840*2160@30Hz HDMI Extender via Fiber to 10km

4K@30Hz HDMI Extender provides long haul transmission of HDMI, audio signals over a single fiber. Engineered for reliability and exceptional high resolution image performance, it uses all-digital technology to deliver perfect pixel-for-pixel transmission of HDMI computer-video images up to 3840*2160 resolution. Designed specifically for AV systems, the Extender includes many integrator-friendly features such as an EDID emulation mode, RS-232 control, and real-time system monitoring.

Specifications

Max Resolution

3840*2160@30Hz

Total Data Rate

10Gbps

Signal Type

HDMI

Wavelength

1310nm

Video Input Connector

(1) HDMI Type A 19-pin Female

Connectors

BIDI LC

Operating Distance

10km@SM fiber

Dimensions (HxWxD)

5.1” x3.1” x1.1”(130x79x28mm)

Working Temperature

-40 to 70°C (-40 to 158°F)

Relative Humidity

0%~95%(Non-condensing)
