NVR204-32C-16P, 32-Channel 16-Port PoE Network Video Recorder, Record 32CH 4K@30fps, Live View/Playback 2CH 4K@30fps, Pre-installed 4TB Hard Drive

NVR204-32C-16P, 32-Channel 16-Port PoE Network Video Recorder, Record 32CH 4K@30fps, Live View/Playback 2CH 4K@30fps, Pre-installed 4TB Hard Drive

520000 CFA

Product Highlights

Support 32 Cameras and up to 4K Resolution
Remote Access via Mobile App, Web Browser and VMS (Video Management Software)
Pre-Installed 4TB Purple Hard Drive
ONVIF® Profile S Conformant
1U-sized, Rack-mountable

NVR204-32C-16P, 32-Channel 16-Port PoE Network Video Recorder, Record 32CH 4K@30fps, Live View/Playback 2CH 4K@30fps, Pre-installed 4TB Hard Drive

Equipped with a 4TB hard disk drive (HDD), the network video recorder (NVR) can record videos from up to 32 cameras, and the storage can be expanded to 40TB in total for its two-bay SATA 3.5” HDD interface. A variety of monitoring methods, including a web browser, monitoring software and mobile App, are available to manage your cameras and NVR easily, ideal for small and medium enterprises, education institutions, hotels and other applications. It features an open architecture that supports for multi-user access and is compatible with ONVIF S protocol, enabling interoperability with IP cameras.

Specifications
IP Video Input
32-Channel
Decoding Format
H.265/H.264
HDMI Output
4K(3840x2160@30fps),1920x1080@60fps,
1920x1080@50fps,1600x1200@60fps,
1280x1024@60fps,1280x720@60fps,
1024x768@60fps
VGA Output
1920x1080@60fps,1920x1080@50fps,
1280x1024@60fps,1280x720@60fps,
1024x768@60fps
Audio Input
1-ch, RCA
Audio Output
1-ch, RCA
Incoming Bandwidth
160Mbps
Decoding Capability
2x4K@30fps,4x4MP@30fps,
5x3MP@30fps,8x1080P@30fps,
16x720P@30fps,32xD1@30fps
Outgoing Bandwidth
64Mbps
LiveView/Playback Resolution
8MP/6MP/5MP/4MP/3MP/1080P/
960P/720P/D1/2CIF/CIF
SATA
4x SATA interfaces
Capacity
4TB (pre-installed Purple HDD), up to 10TB for each HDD
Network Interface
1x 10M/100M/1000M port,8x 10M/100M PoE port (IEEE802.3af/at)
USB Interface
1x USB 2.0(Front panel), 1x USB 3.0(Rear panel)
PoE Power Budget
Max 30W for single port Max 240W in total
Power Supply
AC 100-240V
Interoperability
ONVIF® Profile S Specification at onvif.org
Protocols
P2P, UPnP, NTP, DHCP, PPPoE
Dimensions (HxWxD)
15.7" x 14.2" x 2.9"(400mm x 362mm x 74mm)
Operating Temperature
-10 to 55°C (14 to 131°F)
Quality Certifications
