APC® NetShelter Rack Automatic Transfer Switch, 1U, 16A, 230V, 2 C20 IN, 8 C13, 1 C19 OUT

APC® NetShelter Rack Automatic Transfer Switch, 1U, 16A, 230V, 2 C20 IN, 8 C13, 1 C19 OUT

1124000 CFA

 1-Year Warranty


Product Highlights

Seamless Switching with Transfer Time <10ms
Provides Power Redundancy for IT Equipment
Runs the Built-in Processor to Monitor the Status of Both Power Supplies
Can be Logged in Through the Network Port and Supports SNMP Integrated Management
Automatic Switching Between Primary and Standby Power in Case of Emergency
Suitable for Emergency Power Supply Systems in Many Critical Locations
Compact 1U Rack Form Factor Saves Cooling Costs by Using Fewer Cables

APC NetShelter Rack Automatic Transfer Switch, 1U, 16A, 230V, 2 C20 IN, 8 C13, 1 C19 OUT, 50/60Hz

With Industry leading reliability, agility, and manageability the APC NetShelter Rack ATS provides redundant power to single-corded equipment loads in the IT rack. These are high availability switches offering greater control of your IT equipment from Cloud to Edge.

Specifications
Number of Rack Unit
1U
Color
Black
Mounting Position
Horizontal
Input Frequency
50/60 Hz
Main Input Voltage
230 V AC 1 phase
Main Output Voltage
230 V AC 1 phase
Input Connection Type
IEC 60320 C20 16 A 2P+E
Number of Power Socket Outlets
8 IEC 60320 C13 10 A 2P+E
1 IEC 60320 C19 16 A 2P+E
Height
1.73 in (4.4 cm)
Depth
9.29 in (23.6 cm)
Width
17.01 in (43.2 cm)
Product Weight
8.25 lb (3.74 kg)
Operating Temperature
-5 to 45 °C (23 to 113 °F)
Warranty
1 year
